1. Product Overview: HARTING 09330242701 Han® 3A Hybrid Industrial
Connector
The HARTING 09330242701 is a modular connector from the Han® 3A
series, engineered to deliver reliable power, signal, and data
transmission in industrial automation systems. Featuring a rugged
polyamide (PA) housing with IP65/67 protection, it withstands harsh
environments, including exposure to dust, water, oils, and
mechanical stress. This hybrid connector integrates power contacts
(rated up to 16A), signal pins, and high-speed data modules (e.g.,
RJ45, USB, or coaxial) within a single compact unit. Its tool-free
push-pull locking mechanism ensures quick installation and secure
mating, making it ideal for dynamic applications such as robotics,
motor control systems, and IoT-enabled machinery. Designed for
flexibility, it simplifies complex cabling setups while maintaining
high performance in smart factories.
2. Key Technical Specifications
- Rated Voltage/Current: 400V AC, 16A (per contact).
- Contact Resistance: ≤2.5 mΩ (initial).
- Insulation Resistance: ≥1,500 MΩ (500V DC).
- Operating Temperature: -40°C to +125°C.
- Housing Material: PA (UL94 V0 flame-retardant).
- Protection Class: IP65/67 (mated), IP20 (unmated).
- Mating Cycles: ≥1,000 cycles (mechanical durability).
- Certifications: UL, CSA, CE, RoHS.
- Modular Options: Power, signal, data (Cat.6A), and hybrid configurations.
3. Industrial Applications and Use Cases
The 09330242701 is widely used in automated manufacturing lines for
servo motor power connections, PLC interfaces, and sensor networks
requiring real-time data exchange. In renewable energy systems, it
ensures stable power and communication in solar inverters and wind
turbine control units. Transportation sectors deploy it in electric
vehicle charging stations and railway signaling systems, leveraging
its IP67 rating for outdoor durability. Robotics applications
benefit from its hybrid capability, combining motor power with
sensor feedback for precise control. Additionally, it supports
Industry 4.0 initiatives by enabling protocols like PROFINET and
EtherCAT in smart factories, reducing cabling complexity and
enhancing IoT interoperability.
4. Competitive Advantages and Unique Features
- Hybrid Versatility: Combines power, signal, and high-speed data in a single compact
connector.
- Tool-Free Assembly: Pre-assembled inserts and push-pull locking reduce installation
time by 50%.
- Robust Durability: Vibration-resistant PA housing and gold-plated contacts ensure
longevity in extreme conditions.
- Space Efficiency: Compact Han® 3A design optimizes panel space in control cabinets
and machinery.
- Global Compliance: Meets ATEX, UL, and CSA standards for hazardous environments.
5. Functional Capabilities and Operational Benefits
The 09330242701 streamlines industrial connectivity by centralizing
power and data transmission, minimizing cable clutter and
maintenance costs. Shielded variants eliminate electromagnetic
interference (EMI) in sensitive applications, ensuring stable data
transfer for industrial Ethernet. Its high-temperature tolerance
supports heavy machinery in steel mills or foundries, while the
IP67 rating guarantees reliability in washdown or outdoor
installations. Compatibility with HARTING’s Han® ecosystem allows
seamless integration into existing infrastructure and scalability
for future upgrades. By reducing downtime and enhancing system
uptime, this connector drives efficiency in smart manufacturing and
sustainable automation practices.
| Attribute | Specification |
|---|
| Product Series | Han® Modular Industrial Connector |
| Model Number | 09330242701 |
| Type | Housing/Hood (Backshell) for Han® Modular Connectors |
| Material | Glass-Fiber-Reinforced Polyamide (PA66), UL 94 V0 Flame-Retardant |
| Color | Black |
| IP Rating | IP65/IP67 (when fully assembled and mated with compatible inserts) |
| Voltage Rating | Up to 1,000 V AC/DC |
| Current Rating | 40 A per contact (supports power, signal, and hybrid modules) |
| Temperature Range | -40°C to +125°C (-40°F to +257°F) |
| Contact Resistance | ≤ 1.5 mΩ (dependent on contact type, e.g., crimp or screw-terminated) |
| Cable Entry | Compatible with shielded/unshielded cables, PG/Metric cable glands |
| Shielding | Integrated EMC shielding for EMI/RFI protection |
| Mounting Style | Panel-mounted with screw fixation or DIN rail compatibility |
| Compliance Standards | IEC 61984, UL 1977, CSA 22.2, RoHS, REACH, CCC |
| Applications | Industrial automation, robotics, energy storage, transportation,
heavy machinery |
| Key Features | - Modular design for hybrid configurations (power + data)
- Tool-free assembly
- High vibration/shock resistance
- Pre-assembled inserts for rapid deployment |
| Housing Dimensions | Variable depending on module configuration (refer to Harting CAD
models) |
| Weight | ~300–600 g (varies with configuration) |
| Optional Accessories | Sealing plugs, strain relief kits, grounding clamps, RJ45/coaxial
modules |
